Description

RCR: rectangular CAV unit

• casing in galvanised steel
• galvanised steel adjustment blades with system to control the oscillations, stainless steel rotation shafts on special bearings
• operating range from 50 to 1000 Pa
• working range from 2 to 8 m/s
• operating temperatures between -20°C and +70°C
• tolerance from ± 5% up to ± 15% for low flow rates
• horizontal or vertical assembly
• optional easy recalibration on worksite

RCR...I: with insulated casing

Executions

Assembly:

• install a straight section of duct upstream with the same size as the CAV unit and a length equal to 2 ÷ 4 times the largest dimension
