Description

DL: linear aluminium diffuser with slot and adjustable deflectors with high induction, slot width 20 mm

• optional supply of 1 to 8 slots and continuous assembly with multiple elements
• suitable for operation with ∆t ± 10°
• maximum length per element L = 2000 mm
• standard fastening with adjustable bracket
• made of natural anodised aluminium

A90: 90° blank diffuser - 300x300

Accessories

D: diffuser standard black - white

T: pair of end elements

PL: side entry plenum

PLI: like PL but with external insulation and reaction to fire class B-s2-dO

Circular/oval entries instead of standard

S: damper on plenum entry

Special versions

• 25 mm slot with 25% increase in air flow
• narrower edges 18mm - 14mm

DL ... DTPF: linear return diffuser with G3 filter which can be inspected in the room with 4 slots.

W: RAL 9010 coating

VR: coating according to RAL 9005 / 9006 table
