Description

BMVH: supply grilles with double deflection blades
(1° vertical)

• made of natural anodised aluminium
• fastening with snap-on clips

BMVH-W: like BMVH but RAL 9010

BMHV: like BMVH but with 1st row of adjustable blades

BMV: single row of BMVH horizontal adjustable blades

BMH: single row of BMVH horizontal adjustable blades

Accessories

SC: control damper (sizes over B=600 and H=300 supplied
in multiple parts)

PL: side entry plenum on long side

PT: plenum with rear entry

I: external insulation reaction to fire class B-s2-dO

CT: counterframe for fastening with snap-on clips to wall or duct

Special versions

BM....FV: fastening with visible screws (not included)

• fastening: magnets or latch, on request
• non-standard dimensions on request

VR: coating according to RAL 9005 / 9006 table

Other RAL colours on request
