Description

BASIC: wall-mounted helical fans

• epoxy painted aluminium impeller up to DN 300
• plastic impeller for DN 400
• IP 42 class B motor up to DN 300, DN 400 IP 54 class F with thermal protectors
• frame in thermoplastic material
• galvanised steel protective mesh
• operating temperature -30°C / +70°C
• motor / fan air flow

Special executions

• Winder impeller (on request)
• ATEX execution (on request)
